M24 Eye Bolt Lifting Capacity

Din 529 a anchor bolts stone bolt din 529 b anchor bolts stone bolt.

M24 eye bolt lifting capacity.

Crosby 277 forged shoulder nut eye bolts crosby 277 forged shoulder nut eye bolts crosby 291 forged regular nut eye bolts crosby 291 forged regular nut eye bolts rivet. Never machine grind or cut eye bolt. Load limits are based on a safety factor of 5 to 1. Always tighten nuts securely against the load.

These eye bolts are suitable for wide variety of applications such as tensioning wires securing loads and lifting applications. The larger internal eye diameter offers a versatile alternative to standard grade 4 eyebolts. Grade 8 eye bolts offer up to 4 times higher lifting capacity in certain applications. Available in a wide range of metric and imperial sizes aswell as high tensile steel or stainless steel.

Standard forged eye bolts should not be used with angular lifts. Never use regular nut eye bolts for angular lifts. Always apply load to eye bolt in the plane of the eye. Forged from high tensile alloy steel.

Variety of shapes and designs such as din standard eye bolts collar bs4278 standard eyebolts long shank dynamo type and eyebolts with built in oval links. For angular lifts adjust working load as shown above. If an angular lift is required a properly seated shoulder pattern machinery eye bolt must be used. Crosby m 279 metric forged shoulder type machinery eye bolts crosby m 279 metric forged shoulder type machinery eye bolts nut.

Eye bolts eyebolts and eye nuts eyenuts are also commonly known in the lifting industry as lifting eyes. Din 525 weld studs with hexagon nuts. Not intended for use where the load is perpendicular to the thread. Always use shoulder nut eye bolts for angular lifts.

This is because in these instances the bolt could unscrew and move or it could be twisted and break. Never use eye bolt that shows signs of wear or damage. The definitive version for the implementation of this standard is the edition bearing the most recent date of issue obtainable from beuth verlag gmbh burggrafenstraße 6 10787 berlin germany. Never use regular nut eye bolts for angular lifts.

Working load limits for eye bolts are based on a straight vertical lift in a gradually increasing manner. Never exceed work load limits specified in tables 1 2. Metric thread collared eye bolt generally to din580 range from 95kg to 16 000kg rud rs grade 8 eye bolts non swivel range from 0 1 to 8 0 tonne metric thread dynamo eye bolts to bs4278 range from 100kg to 3200kg. Lifting capacity per eye bolt with bolt fitted at sides of load 45 reproduced by permission of din deutsches institut für normung e.
